Specifications: Type: Straight Knife Cutterhead Style: Floor Standing Model Motor Type: TEFC - Totally Enclosed, Fan-Cooled, induction Motor Power: 1-1/2 HP Motor Phase: Single (1 Ph) Motor Voltage: 115/230 V Cycle: 60 Hz Prewired Voltage: 115 V Motor Current: 15A / 7.5 A Number of Knives: 3 Knife Size (L x W x H): 13-1/16" 1/8" x 5/8" Cutterhead Speed: 4500 RPM Cutterhead Diameter: 2-9/16" Maximum Planing Width: 13" Maximum Planing Thickness: 6-1/8" Full Width Depth of Cut: 1/16" Minimum Planing Length: 14" Cuts Per Minute: 13500 Feed Rate - Planing: 20 FPM Feed Rate - Molding: 10 FPM Dust Port Diameter: 4" Minimum Dust Extraction Volume Required: 350 CFM Overall Dimensions (W x D x H): 23-31/32" x 36-1/2" x 43-1/2" Net Weight: 225 lbs.
