The Minimax FS 41ES is a professional grade, heavy-duty, long bed jointer/planer combination machine designed to meet the needs of the most demanding environments. It features cast iron tables, tilting fence, four-post planner pillar, and quick changeover. This technology gives an exacting finish while reducing ambient noise decibel output significantly. – 10 Horsepower motor – Additional overturning fence for processing of thin workpieces – Cast Iron mortiser with 120mm exhaust hood complete with 16mm chuck Strokes (X-160mm), (Y-120mm) and (Z-105mm) – Dedicated Surface Planer fence (1200mm x 150mm) – Digital-mechanical readout on planer height (1/10mm) – Parallelogram jointer tables – 4 dust-protected planer table columns with trapezoidal threading – Helicoidal thicknesser infeed roller – Sandblasted steel thicknesser outfeed roller – Pre-setting for mortiser – LED readouts & powered movements – American-style jointer guard – Wheels for machine movement – XYLENT Technology Helicoidal Cutterhead with 66 knives – XYLENT Maintenance kit with 10 additional knife inserts (15mm x 15mm x 2.5mm) ** The Minimax FS 41ES comes with an American-style spring-loaded jointer guard and does not come with the pictured European guard in the attached pictures *

The electro mechanical cabinet clamp action e is the solution for the assembly of cabinets. Intuitive and easy to use. This semiautomatic machine is suitable for all cabinet manufacturers, with low productive volumes (up to 30 cabinets/shift).

The electro mechanical cabinet clamp action p is the solution for the assembly of cabinets. The automatic set-up allows to a simple use of the clamp. This automatic machine is suitable for all cabinet manufacturers, with medium productive volumes (up to 50 cabinets/shift).

The Class TF 130PS is the workhorse of the SCM shaper line. It has a very robust structure and all the controls can be accessed on the front of the machine for easy use. An integrated sliding table further increases the flexibility of this machine. A mechanical digital reader ensures the precision of the spindle adjustment. 3ph/ 220V 11HP fixed 1 1/4 MK5 interchangeable spindle 5-speed Aluminum fence w/ mechanical adjustment Sliding table Tenoning kit

A must for the serious woodworker, the Class TF 130 is the SCM shaper that combines quality and value for your investment. It has a very robust structure and all the controls can be accessed on the front of the machine for easy use. A mechanical digital readout ensures the precision of the spindle adjustment. 3ph /220V 11 HP Fixed 1 1/4 " MK 5 interchangeable spindle 5-speed aluminum fence w/ mechanical adjustments

The Class TI 120 is one of SCM Groups finest manual tilting spindle shapers. The tilting spindle allows craftsmen to use more creativity in designing high-end, custom products. The quality and flexibility of this machine are especially appealing to architectural millwork operations.

Technical Specifications Motor 3-phase 230v Horsepower 9Hp Flywheel Diameter37” (940mm) Table Size32.28” x 45.66” (820x 1160mm) Table Tilt0° -45°Cutting Height/Depth22” (560mm)Cutting Width36.2” (920mm) MinBlade Length259.44” (6590mm) Max Blade Length264.17” (6710mm) Overall Dimensions(Used Upright/Vertically)61” x 36.2” x 112.59” (155x 92x 286cm) Net Weight1,584 lbs.(720kg) Total Dust Extraction Ports2 Total Dust Extraction Ports Diameter5.5” (140mm)

Technical data Max. useful spindle length 140 / 5.5 mm / inches Spindle speed 3000/4500/6000/7000/10000 rpm Max. diameter of the profiling tool 250 / 9.8 mm / inches Max. tool diameter retractable under the table at 90° 320 / 12.6 mm / inches Max. diameter of the tenoning tool 300 / 11.8 mm / inches Three-phase motor power 10 Hp

Technical data Max. useful spindle length 140 / 5.5 mm / inches Spindle speed 900 – 12000 rpm Max. diameter of the profiling tool 250 / 10 mm / inches Max. tool diameter retractable under the table at 90° 300 / 11.8 mm / inches Max. diameter of the tenoning tool 300 / 11.8 mm / inches Three-phase motor power 13 Hp

Technical data Longitudinal stroke mm 200 Vertical stroke mm 160 Transversal stroke mm 125 Tool spindle diameter mm 1÷16 Spindle speed rpm 3000 Three-phase motor starting from kW/Hz 1,5 (1,8) / 50 (60)

Minimax ME 25 Single Sided Edgebander - Control panel on machine infeed side - Machine frame made of high rigidity ribbed steel to guarantee an excellent support for the operating units - Top thick steel pressure beam with rubber coated wheels - Exclusive feed belt system - Manual adjustment of top beam with automatic positioning of the operating units to the selected panel thickness - Numeric indicator of the selected panel thickness - Wood strip loading device - Glue smoke-specific exhaust outlet; centralized extraction of the other dusts - Panel support roller which can be extended on the entire length of the machine - Safety enclosure - Electrical cabinet with PLC, padlockable main switch and overload protection - Emergency push buttons - Scraping unit (cutter radius 3mm) - Buffing unit (two independent motors – 2,800 rpm) - Adjustable infeed fence with numeric readout - Automatic lowering of the glue pot temperature after temporary non-usage

High productivity edge bander with high quality performance. me 40, further enhanced compared to the previous version, with the new rounding unit that allows to obtain high quality finished products, without further processing, allowing a considerable saving of time and increasing ease of processing. Technical Data • Work table dimensions mm 3465 x 710 • Min. ÷ max. thickness of rolled edges mm 0,4 ÷ 3 • Max. thickness of edges in strips mm 5 • Min. ÷ max. panel height mm 8 ÷ 50 • Min. panel length/width mm 190/110 Feed speed m/min 9

Technical data profiset 40 Min./max. working width (finished section) 23/180 mm Min./max. working height (finished section) 6/105 mm Feed speed 6 – 12 m/min Spindles speed 6000 rpm

Technical data profiset 60 Min./max. working width (finished section) 25 (15 opt.)/230 mm Min./max. working height (finished section) 6/120 mm Feed speed – m/min Feed speed (variable with inverter) 25-May m/min Spindles speed 6000 rpm Axial adjustment of spindles with respect to the worktable 40 mm

Technical data Nova tf 110 Max. useful spindle length 140 / 5.5 mm / inches Spindle speed (at 50 Hz) 3000/4500/6000/7000/10000 rpm Max. diameter of the profiling tool 250 / 9.8 mm / inches Max. tool diameter retractable under the table at 90° 320 / 12.6 mm / inches Max. diameter of the tenoning tool with spindle diam. 30-35 (40-50) 300 / 11.8 mm / inches Three-phase motor 8 Hp

TECHNICAL FEATURES Blades tilting 90° ÷ 45° Max. saw blade diam. with scoring blade installed mm (in) 400 (15.75”) Max. saw blade projection from table at 90°/45° mm (in) 140/97(5.5 / 3.81”) Scoring blade diameter mm (in) 120 (4.75”) Squaring stroke mm (in) 3200 (10.5’) Cutting width on parallel fence mm (in) 1500 (62.94”) Other technical features: Three-phase motor 11kW (15hp) 60Hz Exhaust outlets diameter 120 (4.75”) MINIMUM INSTALLATION REQUIREMENTS Power absorption A 42 Voltage frequency 230V 60Hz

Servo Driven Edgebander, Automatic single sided edgebander designed to be used for edgebanding straight vertical profiles with coiled material (veneer and PVC) and with strips (high-pressure laminate and solid wood) with a maximum thickness of 8mm. Machine Base The machine base is made of a tubular steel structure and is designed to assure maximum stability and accuracy. Electronic Top Pressure Beam All operating units raise and lower simultaneously when the pressure beam is adjusted. No adjustment is required for the glue roller when changing panel thickness. The pressure beam has two rows of staggered pressure rollers with steel bearings. Capacities and Speed • Edgebanding thickness: .4mm – 6mm (.016-1/4”) • Guillotine capacity: 3mm • Feed speed: 36 ft/min. • Panel height: 3/8” min – 2 1/8” max • Minimum panel length: 5 1/2” • Minimum panel width: 2 3/8” • Minimum distance between panels: 22”

• Rubber coated pressing rollers before and after working unit • 1 HP two speed feed unit. Feed speeds set at 15 or 30 feet per minute • Y-Delta two-stage reduced voltage starter on main motor • 2 roller Infeed and outfeed table extensions • Automatic Electronic Table Positioning Device • Adjustable sanding drum and pad position for micro precision adjustment • Electronic digital thickness readout of work table position • Powered table lifting by means of four heavy duty motor and lifting columns double fastened at both top and bottom of the lifting columns to provide exceptional table stability • Electronic tracking of abrasive belt • Automatic feed mat tracking • Pneumatic belt tensioning with center fulcrum to compensate for tapering of abrasive belt • Front and rear emergency stop buttons • Automatic emergency stop of machine for: - sanding belt breaking, tensioning, over tracking - opening of the access door to the operating groups - absence of compressed air - overload on main motors • Amperage meter for main motors allows maximum utilization of available horsepower • Main disconnect switch with the ability to be locked out by padlock • In feed flexible steel hold down, and anti-kickback plate • 50 shore, negative profile (waffle style) rubber feed mat • LOGIC 50 K Electronic Programmer for timing/anti-dubbing • of the pad

Technical Specifications Worktable Dimensions: 1200 x 730mm Working Length of Spindle (C.E.) Diam. 30-35 (40-50): 140mm (180) Spindle Base Projection from Table: 52mm Spindle base projection from table with interchangeable spindle: 92mm Max tool diam. retractable under worktable with rings (with "Fast" section table): (300 x 85mm) Spindle fence stroke w/ mechanical programming (positioning with respect to the spindle axis): 125mm (from -125 to +125) External diameter of exhaust outlet on spindle moulder hood: 120mm External diameter of exhaust outlet on base (for the forced electrospindle aircooling 7.5 kW): 120mm Air flow speed of exhaust system: 20 M/sec Exhaust system air consumption: 1700 M3/hr

Technical data Max. saw blade diameter with mounted scorer 400 / 16 mm / inches Maximum saw blade projection from table to 90°/45° 140/97 5.5/3.8 mm / inches Cutting width on rip fence (Rip capacity) 1270 / 50 mm / inches Max. squaring stroke of sliding table saw 3200 / 126 mm / inches Three-phase motor 9,5 (50) - 11 (60) Hp / Hz

Technical data Max. saw blade diameter with mounted scorer 315 / 12 mm / inches Sawblade arbor size 25 / 1 mm / inches Maximum saw blade projection from table to 90°/45° 100/70 3.9/2.75 mm / inches Cutting width on rip fence (Rip capacity) 1270 / 50 mm / inches Max. squaring stroke of sliding table saw 1600 / 63 mm / inches Three-phase motor 11 Hp Indipendent scoring motor 1 Hp

The Nova F 520 T is a heavy duty, long bed 20” jointer designed to meet the needs of the most demanding environments. It features cast iron tables, a tilting fence and a quick change Tersa cutterhead.

Technical data L’invincibile f 7 Cutterhead working width 520 / 20 mm / inches Cutterblock diameter / n° of standard knives 120/4 mm/n° Dimensions of standard knives 520 x 35 x 3 mm With XYLENT Spiral Helical Cutterhead: 120/84 mm/n° Cutterblock diameter / n° of standard knives 15 x 15 x 2.5 mm Dimensions of standard knives Jointer bed length 3008 / 118 mm / inches Three-phase motor 11 Hp Max. stock removal 8 mm

About This Machine: The K360 is an automatic single sided edgebander designed to be used for edgebanding straight vertical profiles with coiled material (veneer and PVC) and with strips (high-pressure laminate and solid wood) with a maximum thickness of 6mm. Machine Base The machine base is made of a tubular steel structure and is designed to assure maximum stability and accuracy. Top Pressure Beam All operating units raise and lower simultaneously when the pressure beam is adjusted. No adjustment is required for the glue roller when changing panel thickness. The pressure beam has two rows of staggered pressure rollers with steel bearings. Capacities And Speed – Edgebanding thickness: .4mm – 6mm (.016-1/4”) – Guillotine capacity: 3mm – Feed speed: 36 ft/min. – Panel height: 3/8” min – 2 1/2” max – Minimum panel length: 5 1/2” – Minimum panel width: 2 3/8” – Minimum distance between panels: 20” Glue Station Teflon coated glue pot to facilitate glue changeover. Warm up time is approximately eight to ten minutes. The unit is also equipped with a quick disconnect plug for changing from one pot to another.

High performance and versatility: olimpic k 560 is designed for companies requiring to process many panels per day even though they may be different from one to another. olimpic k 560 has several solutions that guarantee always the best machining on any panel type. Capacities and Speed – Edgebanding thickness: .4mm – 6mm (.016-1/4”) – Guillotine capacity: 3mm – Feed speed: 40/60 ft/min. – Panel height: 3/8” min – 2 1/8” max – Minimum panel length: 5 1/2” – Minimum panel width: 2 3/8” – Minimum distance between panels: 20”

The machine base is made of a tubular steel structure and is designed to assure maximum stability and accuracy. Pressure Beam: All operating units raise and lower simultaneously when the pressure beam is adjusted. No adjustment is required for the glue roller when changing panel thickness. The pressure beam has digital height indicators and a double row of pressure rollers with steel bearings Capacities And Speed: – Edgebanding thickness: .4mm – 3mm (.016-1/8”) – Guillotine capacity: 3.0mm – Feed speed: 30 ft/min. – Panel height: 3/8” min – 1 15/16” max – Minimum panel length: 5 1/2” – Minimum panel width: 2 3/8” – Minimum distance between panels: 22” Glue Station Teflon coated glue pot to facilitate glue changeover. Warm up time is approximately eight to ten minutes. The unit is also equipped with a quick disconnect plug for changing from one pot to another.

This 16” jointer/planer combo machine offers power and precision in a compact size for any shop. With long jointer tables, and sturdy fence, this machine is a quality product, made in Italy, for a value price. Find out why this machine may be perfect for you. – 4.8 Horsepower single-phase motor – 16″ Jointer/planer cutterblock – 70″ Jointer table length – Precision-ground cast iron tables – American-style jointer guard – Quick-tilting jointer fence – Jointer tables open away from the operator – Two independent dust collection ports – Tool set & owner’s manual Depending on the desired cutterhead, the Minimax FS 41C also comes with: – 3-knife “Tersa” quick-change cutterhead – Xylent helical cutterhead ** The Minimax FS 41C comes with an American-style spring-loaded jointer guard and does not come with the pictured European guard in the attached pictures **

Technical data Cutterhead working width mm 630 With TERSA Straight-knife Cutterhead: Cutterblock diameter / n° of standard knives Dimensions of standard knives mm/n° mm 120/4 630 x 30 x 3 With XYLENT Spiral Helical Cutterhead: Cutterblock diameter / n° of knives Dimension of standard knives mm/n° mm 120/105 15 x 15 x 2.5 Min. – max. planer working height mm 3.5 – 300 Planer feed speed m/min 4 – 20 Three-phase motor Hp 12

Edge thickness mm 0,4 - 6/8 (12 opt.) Panel thickness mm 8 - 60 Feed speed m/min 12 - 18 Compressed air bar 6

Compact edge bander with a sturdy framework that guarantees reliability and repeatability. Thanks to its technological solutions, olimpic 300 is ideal for craftsmen who want to start edging professionally, with ease of use and maximum finishing quality.
